Technikpool Equipment – Lighting

Deposit

You will always need to pay a deposit of 50. Then you can borrow stuff ‘for this amount’. As a consequence, if the sum total is less than 50, you will pay the fixed amount. If the equipment deposits required exceed 50, the specific sums are added to the deposit.

Overview Lighting

Here you will find a short overview of our lighting equipment. Please take note of our Rental conditions. –> to more Rental Equipment

 Rental UnitAmountDepositDetails


Light controllerLight mixer120Stairville LED Commander 16/2 [Controller of 16 DMX512 units, 16 colour presets on 2 banks, 16 chasers (running lights) on 2 banks, Fader for fade and scene time, auto, music and manual modes, 2 aux channels, blackout, full on, DMX output: XLR 3 pol., Midi in/out/through, audio input: rca, construction: 19”, 4 HE]

Light controllerLight mixer130Zero 88 Jester ML48 [48 channels, up to 30 moving lights, 24/48 presets, 2 preset masters, 1 grand master, 999 save places, sub-master fader, 4x LCD display, soft-patch: max. 512 channels, unit library (1700 moving lights activations), pan/tilt: 3 wheels, movement effect generator, external power supply, connection (DMX): XLR 5-pol (f), input (DMX): XLR 5-pol (m), audio connection: 6.3mm stereo jack, desk lamp connection (USB), USB output (for saving), SVGA monitor output, measurements (LxBxH): 970x278x90mm, weight: 12.0kg] Optional: desk lamp, monitor (for simplified programming)

Light controllerSoftware light mixer120Dashlight DVC4 Gold, compatible to DVC4 and DVC3 software, 1024 channels, connection over mini USB, 128k memory, clock/calendar function, dry contact ports: 8

Light controllerSoftware light mixer150Dashlight DVC5 Gold, compatible to Daslight5 Software, 1024 channels, connection over USB-C

Stage/Mood lightingSpotlight PAR 641210Stairville LED PAR 64 RGB [short housing, 183 10mm LEDs, 7 channels, RGB colour mixer over DMX or stand-alone program, XLR 3 pol. Inputs/outputs, sound to light function].
Attention: DMX control defective on two of 12 devices.

Stage/Mood
lightning
Battery PAR WDMX820Varytec Battery Event Par IP65
with Wireles DMX
Charging time: Approx. 6 hours
Battery operation at full light output: Approx. 7 hours

DMXWireless DMX
Sender/Recever
450Stairville WLS-DMX Pro G5

Stage/Mood lightingLED Bar220Eurolite LED Bar 2 RGBA 252/10 Bk 40° [music control, stand-alone and DMX modes, occupies 4, 6 or 19 DMX channels, 252x 10-mm LEDs]

Stage/Mood lightingLED Bar220Eurolite LED PIX-16 QCL Bar
With 16 x 4-W-RGBW-LED (4in1)
Stroboscope effect
21 Integrated show programmes
Direct colour selection for 15 colours Controllable via stand-alone, master/slave function, DMX, QuickDMX via USB (optional), music control via microphone, IR remote control, DMX connection: XLR 3-pin In / Out

Stage/Mood lightingLED light system250Eurolite LED KLS-406 RGB DMX [6 Spots, DMX512 controler (occupies 21 channels), music control over built-in microphone, strobe effect, auto mode, internal programs, Master/Slave functions, connection ready, 1080 10mm LEDS (every 60 LEDs per colour per spot), power consumption: 230W, DMX512 connection: 3-pol. XLR, measurements (LxBxH): 1870x55x310mm, weight: 11kg]
Zubehör(optionaler) Fußschalter für LED Lichtanlage210Functions: Black out, Freeze, Music-controlled and auto-program for colour range, Connected with 5-pol. connection cable (ca. 5m)]

StagelightLED-Fluter230Light source: 18x 4-in-1 8W RGB WW LEDs
Beam angle: 35°
Colour temperature of the white LEDs: 3200 K
Control: DMX (4 / 6 / 8 channels)
Automatic programs
Music control with adjustable sensitivity
Static colours are adjustable via the display
DMX input and output: XLR 3-pin
Power input and output: IEC
Power supply: 110 – 230 VAC, ~ – 50 / 60 Hz
Power consumption: maximum 120 W
Dimensions (W x H x D): 380 x 200 x 160 mm (height 440 mm with bracket and barn doors)
Weight: 5.52 kg.
Attention: DMX control defective on one of four devices.

StagelightLED Moving Head450PAN / TILT 8 / 16-bit (PAN max. 540°, TILT max. 270°)
Automatic pan / tilt correction
Control via DMX 512 (14 or 8 channels), master / slave mode, or sound-to-light control via the integrated microphone
Colour wheel with 8 colours + white (8 full colours, 8 split-colours, and rainbow effect)
Gobo wheel with 7 rotating gobos + open (indexable- + interchangeable, gobo shake function, gobo direction forwards and backwards)
Rotating prism
Light output: 20,000 Lux @ 1 m
Motorised focus
Shutter 0-13 Hz
Electronic dimmer 0-100%
Beam angle: 14°
Power consumption max. 135W, 230V AC 60/50 Hz
Weight: 8 kg
Dimensions W x D x H: 240 x 280 x 370 mm
Attention: DMX control defective on one of four devices.

StagelightLED Moving Head450Stairville MH-100 Beam [Light source: 36 3W CREE LEDs (8x red, 10x green, 10x blue & 8x white)
Light output: 62,000 Lux @ 1 m
Optics: Beam angle 8 °
Dimmer: Linear 0-100%
Shutter: Electric
Strobe effect
Rotation: PAN: 630 °, TILT: 220 °
Control: DMX-512 (9 or 14 DMX channels), Sound Active (music-controlled) or Master / Slave
Digital display with 4 buttons for setting all functions
Mounting: Quick-lock Omega brackets
DMX input and output: 3-Pin XLR
Power supply: 100 – 240V, 50Hz / 60Hz
Max. power consumption: 175 W
Cooling: Via built-in fan
Dimensions (H x W x D): 320 x 260 x 148 mm
Weight: 4.9 kg]

Party-LightLED-Moonflower220LED DMX-512 Moonflower LEDs : 64 Red, 64 Green, 64 blue and 64 White
2 DMX Channel Modes (4 Channel mode or 256 Channel mode)
4-Button LED DMX Display
Linkable via XLR 3 operation modes: DMX, Sound Active & Master/Slave
Sound active from built-in programs
Strobe function
Beam angle: 50 degrees
Consumption: 29W maximum
Operation: AC 100-240V, 50/60Hz
Dimensions (LxWxH): 312x306x334 mm
Weight: 4.2 kg

Party-LightLED-Matrix Flower-Effekt220Stairville maTrixx FX-440 [Control by DMX, Sound-to-Light, automatic mode, max. Consumption: 15W, 144 LEDs ( 36 Stck. red, green, blue and white), XLR 3-pol. In- and Out]

Party-LightLED-Mushroom230Varytec LED Magic Mushroom [224 RGB-LEDs, DMX & Sound-to-Light-Function]

Party-LightLED-Lasereffekt1303 in 1 LED-Laser effect: Sound Active, Show Mode or DMX Controllable, 26 DMX Channel Modes, DMX-512 Protocol, 0-100% Dimming, Key lock on rear panel to switch laser On/Off

Party-LichtLED-Ball-Effekt130American DJ Spherion TRI
3 DMX Channels (Rotation Speed/Direction; Dimmer/Strobe; Color)
1 or 3 Channel DMX Modes
Beam Angle: 270 degrees
Power Draw: 27W Max
Operation modes: Sound Active, Master/Slave or DMX-512
Linkable via 3-pin XLR cable
4-button DMX display on rear panel
Multi voltage: 100V~240V, 50/60Hz (IEC input only)
Long life LEDs (50,000 hr. rating)
LED Source: 5x 3-Watt TRI Color (3-IN-1) LEDs
Dimensions (LxWXH): 320x320x422mm
Weight: 5kg.

Party-LightMirror ball + Motor120Mirror ball with sturdy plastic core real glass facets 10 x 10 mm diameter: 30 cm Weight: ca. 1,850 kg

Party-LightLED-Spot for Discokugel220Eurolite LED PST-15W QCL DMX-Spot
6 or 8 DMX channels,
colors red, green, blue and white
For illuminating mirror balls,
Functions: static colors, RGBW color change, internal programs, dimmer, strobe effect, Master/Slave function,
Sound-controlled via built-in microphone

LED: 1 x high-power 15 W 4in1 QCL RGBW
Controlling by Stand-alone; DMX

Party-LghtBubblemaschine130ADJ Bubbletron GO
Battery powered and rechargeable Power: 24 W (120 V), 10 W (230 V)
Fluid consumption. 1 litre every 50 min (120 V), 1 litre every 90 minutes (230 V)
Automatic switching power supply: AC 120 – 230 V, 50 / 60Hz (charging unit: DC12V 1000mA)
Battery charging time: 6 hours
Battery life: 5 hours (full charge)
Dimensions (L x W x H): 352 x 176 x 209 mm
Weight: 2 kg

Party LightHazer150Stairville Hz-200 Power output of the heating element: 615 W
Max. haze output: 34 m3 per minute
Fluid tank capacity: 1.2 l
Warm-up time: Approx. 2 min.
Power supply: 230 V (AC), 50 Hz
Dimensions: 280 x 330 x 380 mm
Weight: 7.5 kg

Party LightSmoke machine150Smoke Factory, Spaceball II, Power: 650 W
Power supply: 240 V / 50 Hz
Capacity of the fluid container: 750 ml
Fluid consumption: 60 ml/min at max. output, 15 ml/min at continuous output
Fogging time: Approximately 35 sec at 100% output
Continuous output at about 50%
Drive Capability: DMX 512
0 – 10 V analogue
Standalone
Integrated timer
Heating time: Approximately 7 minutes
Microprocessor-controlled temperature regulation
Dimensions (L x W x H): 33 x 19 x 33 cm
Weight (without fluid): 9 kg
LightConstruction spotlight220Power: 500 W
LightDouble Construction spotlight3302 halogen lamps with stand, height adjutable up to 2m, 2x 400W]
LightLED Construction spotlight220Construction spotlight: LED battery-powered work lamp 2000 [Power: 22W, Light length: 2.5h (2000lm) / 6h (1500lm), Light source: 9x 2.5W SMD-LED, Weight: 2kg, incl. battery]
LightLED Construction spotlight220Construction spotlight: Ampercell Battery-powered construction spotlight, 10 W [Power: 10W, Light strength: 800lm, Weight: 980g]
LightLED Construction spotlight320ChiliTec 20W LED Construction spotlight with battery “WL Slim”, 230V, 1500 Lumen, 4200K neutral white
LightLED Construction spotlight220Brennenstuhl Mobile Chip LED lamp ML CN 130 V2, not battery powered!
LightHeadlamp210
AccessoryLight stand with short traverse210Height 177–310cm, transportable length 137cm, max. load 18kg, weight 11kg traverse with 5x protective contact and DMX outputs
AccessoryTraverse210Width: 3m (up to 4.5m, optional expansion), Height: 1.2m bis 3m, max. load 25kg, Weight: 12kg
AccessoryBig traverse160Traverse Bundle – consists of: 3 x Global Truss F32200 2m Traverse, 2 x Millenium BLS-2700 Speaker/Light crankable tripod, 2 x Stairville Tavers Adapter 2-Point + bags
AccessoryLight stand210Height: 180–322cm, max. Load 20kg, Weight 3,2kg, TV-spigot-intake Ø 28mm
AccessoryFloor light stand1010Floor light stand 17725 König&Meyer, black
